Temphawk Specifications

Hardware Specifications


Dimensions (in mm): 68 x 86 x 36
Weight: 300g
IP Code: IP67
Sensors: Temperature and Humidity (external)
Temperature sensor working range: -40ºC to +125ºC
Temperature sensor resolution: 0.015ºC
Temperature sensor accuracy: +/- 0.2ºC
Humidity sensor range(%RH): 0/100%
Humidity sensor resolution: 0.01%RH
Humidity sensor accuracy: +/- 3%RH
Battery: Lithium Battery
I/O Interface 2 Red LED Lights
Micro USB Type-B (waterproof) for power
Protocol: Sigfox
Radio Configuration Zones: 1
2
4
Transmission interval: Every 10 minutes
Certifications: Sigfox Ready, Class 0 (Highest class)
RoHS
FCC
CE
Low Voltage Directive (LVD)
PB free
CE
FCC
ROHS
RCM

Sigfox Ready

The Sigfox Ready certification measures the radio performance of the device. Temphawk is Sigfox Ready with the highest Class rating, making it good for indoor and outdoor use.

If you have purchased a Temphawk device and need its product certificate you can refer to the table below.

Regions RC End Product Certificate Sigfox Partner Network
Europe, South Africa 1 P_00BE_B271_01 Link
Canada, USA, Mexico, Brazil 2 P_00BE_77FF_01 Link
Latin America (CR, ES, HN, PA, CO, AR)
APAC (TW, SG, AU, NZ, HK)
4 P_00BE_B9B5_01 Link

Certified Sensor Probe


Temphawk sensor has been tested and certified by SGS for accuracy and resolution. It is one of the few sensors which can accurately measure up to two decimal places.

The sensor’s material is also FDA approved, making it good to be in direct contact with food.
